Dual Hole Car Spark Plug Ignition Tester Detector Ignition Plug Diagnostic

Dual Hole Car Spark Plug Ignition Tester Detector Ignition Plug Diagnostic
Application Range: 12V Gasoline vehicles car spark plugs

السعر = 65 دينار
للطلب او الاستفسار الاتصال = Click to Show Phone Number 9627920792XX

Dual Hole Car Spark Plug Tester Detector have two testing holes, you can test two spark plugs meanwhile and and if you suspect any spark plug works improperly you could compare and test to make accurate judgment

Usage: Test spark plug performance and ignition strength
Application Range: 12V Gasoline vehicles car spark plugs
Frequency:1000-6000rpm/min
Power Adapter: Input 100-240V AC
Output 12V 1A DC

Notice
1. Please Turn Off Power before you place spark plug(It is the most important, please make sure you are safe at first)
2. The Spark Plug Tester is a high-voltage detector, so do not touch spark plug with hand at work to avoid danger
Car Spark Plug Test principle
In automobile ignition system, the high-voltage ignition coil generates a high-voltage (10000 volts or more), and the spark plug diverts it form
high -tension ignition coil into the cylinder engine, spark between the spark plug electrodes will ignite the mixture. The Detector could tell the
good spark plugs from the bad by the strength of the spark.

User Manual
1.Place the Spark Plug into tester hole 1 or 2; If you want to compare the new spark plug and old one, place new spark plug into hole 1 and the old on into hole 2
2.Connect to power supply
3.Turn the key switch 4 clockwise to turn on tester, indicator 3 will light up, tester is now working at 1000rpm/min.
4. Again turn the key switch 4 clockwise,you can adjust the working frequency between 1000rpm to 5000rpm/min.
The higher the frequency, the stronger the spark strength

Pack list
Spark plug tester

الرمز = 40
الرقم = 1
